The 1.8" TFT with Capacitive Touch Panel has 128x160 color pixels. It can detect two touch points and highly responsive compare to resistive touch. It can be used with every kind of microcontroller. The display interfacing is based on SPI or IO port(8080 / 6800 MCU). The Capacitive Touch panel supports two touch points and using I2C interfacing.
MCU features and performance: Minimum instruction execution time can be changed from high speed 20 MHz to ultra low-speed 1 MHz High speed on-chip oscillator (HOCO) : 20 MHz Different potential interface: Can connect to a 2.5/3 V device when operating at 4.0 V to 5.5 V Self-programming On-chip single-power-supply flash memory Standby function: HALT and...
MCU features and performance: Minimum instruction execution tim e can be changed from high speed 24 MHz to ultra low-speed 1 MHz High speed on-chip oscillator (HOCO) : 24 MHz Different potential interface: Can connect to a 2.5/3 V device when operating at 4.0 V to 5.5 V Self-programming On-chip single-power-supply flash memory Standby function: HALT,...
MCU features and performance: Minimum instruction execution time can be changed from high speed 32 MHz to ultra low-speed 1 MHz High speed on-chip oscillator (HOCO) : 32 MHz Different potential interface: Can connect to a 2.5/3 V device when operating at 4.0 V to 5.5 V Self-programming On-chip single-power-supply flash memory Standby function: HALT,...
Relancer USB to UART converter board Features: Based on CP2102 from Silabs USB 2.0 compliant, full-speed (12 Mbps) No external crystal required User-programmable custom Baud rates Baud Rates: up to 2 Mbps LEDs indication for transmitting and receiving
Relancer E10 on-chip debugger adaptor board Features: Convert the E10’s JTAG 14pins to simple 4pins(Vcc, Gnd, Tool and Reset) An universal adaptor for all Relancer RL78 and RX boards Reset button is included LED indication for the power
Tamiya 70172 Universal Plate Feature: Dimension is 210 x 160mm A plastic plate with 41 x 31 grid of 3 mm holes spaced 5 mm apart, which provides space for many mechanical connections.
Edison Module IoT External Antenna Part Number: EDI2.SPOF.AL.MP Dual-core CPU and single-core microcontroller Integrated Wi-Fi* certified in 68 countries, Bluetooth* 4.0 support, 1 GB DDR and 4 GB FLASH memory simplifies configuration and increases scalability 40 multiplexed GPIO interfaces with expansion board options for total project design...
The 1.8" TFT with Capacitive Touch Panel has 128x160 color pixels. It can detect two touch points and highly responsive compare to resistive touch. It can be used with every kind of microcontroller. The display interfacing is based on SPI or IO port(8080 / 6800 MCU). The Capacitive Touch panel supports two touch points and using I2C interfacing.
